Anyone built a barrel wood stove for their shop? Was it worth it or am I just better off not being cheap and buying a legit wood stove. It’s a non insulated dirt floor pole barn but I’m just looking for something to knock the chill off in there
Barrel stove for shop
- Thread starter brockel
- Start date
Irrelevant
Well-known member
Parents looked into it. Unless it was certified the structure wouldn't be insurable
I ran into the same problem. I went with a used Blaze King.
Irrelevant
Well-known member
High Efficiency Wood Stove - general for sale - by owner - craigslist
High Efficiency Wood Stove Heatilator 35 tall 27 wide 32 front to back $650 or best offer Text or call and leave message
billings.craigslist.org
BackofBeyond
Well-known member
While it's tin walls, barrel stove will work just fine to knock the nip off. Once you decide to not be cheap and insulate your walls, then go for a legit stove.
For the price of a couple barrels, some 2" tube, and a box fan you can at least keep your fingers from freezing.
I’d be scared to see my electric bill from that one. It’s a 30x40 with 12’ sidewalls
Mallardsx2
Well-known member
- Joined
- Apr 4, 2015
- Messages
- 2,611
Torpedo heater.
Seriously. Do the math. It’s the right way to go.
Seriously. Do the math. It’s the right way to go.
Tradewind
Well-known member
- Joined
- Aug 19, 2015
- Messages
- 4,638
I have built 2 of them. Worked great. Used old racing fuel drums. Make sure they were dry, eh.
Bot a kit at one of the farm supply type stores. I put the vent in the bottom of the feed end and the exhaust
at the top pf the other end. Air flow was phenomenal.
Used old fire bricks out of someones old wood stove to line the bottom. Otherwise the metal will not last long.
put some sand in first.
Put it at a cabin on a concrete floor so we did not check with insurance. If you want to see if they'll accept it
you'll prob need a concrete pad and nothing even close.
Best working stove we ever had in there
Bot a kit at one of the farm supply type stores. I put the vent in the bottom of the feed end and the exhaust
at the top pf the other end. Air flow was phenomenal.
Used old fire bricks out of someones old wood stove to line the bottom. Otherwise the metal will not last long.
put some sand in first.
Put it at a cabin on a concrete floor so we did not check with insurance. If you want to see if they'll accept it
you'll prob need a concrete pad and nothing even close.
Best working stove we ever had in there
Arcola
Well-known member
Had one in a 30x40 with nothing but poly on the ceiling. It was comfortable at 20 degrees with a box fan for circulation. At -20 it was worthless. @Tradewind has good suggestions about intake and exhaust. I screwed up the intake on my first go round. Insulated the structure the next summer and barely needed a heater the next winter. I’ll put my money and effort into insulation first, going forward.
Yes lve built several. And have 2 now. They work very well. I used the forge cast kit that is sold. It looks nice and it does a good job. As wrote sand n 2"x8"×16" cement paver blocks on the bottom. I put one barrel on 8x16 blocks. 4 cement blocks about a foot apart the barrel set into. Distributes the weight well and I broke the leg freighting it to our cabin.
It's nice to weld in a flat piece of steel to cook on but a piece of steel welded to the top works good too. Also nice that longer wood can be used.
It's nice to weld in a flat piece of steel to cook on but a piece of steel welded to the top works good too. Also nice that longer wood can be used.
belshawelk
Well-known member
That was all we used to heat our house. 55 fallen barrel. Can take 40” wood pieces with ease. Issue is finding an old school double wall or thick barrel. Not the cheap ones today. We would get about 10 years out of ours. Massive heat. We would literally turn barrel red hot and it glowed at night. My dad welded legs up to top so we would put a flat piece of steel like a table. We could cook on it. Great for keeping coffee and water hot.
